Revotron 1.2T
168
List of Diagnostic Troubleshooting codes for Revotron 1.2T:
Sr. No DTC CODES
DTC DESCRIPTION
1
P0053 HO2S1 Heater Resistance(Bank 1 sensor 1)
2
P0054 HO2S2 Heater Resistance(Bank 1 sensor 2)
3
P0106 Manifold Absolute Pressure Range/ Performance
4
P0107
Manifold Absolute Pressure/Barometric Pressure Circuit Low i.e., signal line
short circuit to ground or sensor supply line open
5
P0108
Manifold Absolute Pressure/Barometric Pressure Circuit High, Signal line open,
short to Battery & sensor ground pin open
6
P0112 Intake Air Temperature Sensor Circuit Low
7
P0113 Intake Air Temperature Sensor Circuit High
8
P0116 Engine Coolant Temperature sensor Circuit Range/ Performance
9
P0117 Engine Coolant Temperature Sensor Circuit Low
10
P0118 Engine Coolant Temperature Sensor Circuit High
11
P0122 Throttle/Pedal Position Sensor/Switch "A" Circuit Low
12
P0123 Throttle/Pedal Position Sensor/Switch "A" Circuit High
13
P0130 O2 Sensor Circuit(Bank 1 Sensor1)
14
P0131 O2 Sensor Circuit(Bank 1 Sensor1)
15
P0132 O2 Sensor Circuit High Voltage(Bank 1 Sensor1)
16
P0133 O2 Sensor Circuit slow response(Bank 1 Sensor1)
17
P0135 O2 Sensor Circuit Signal circuit short to heater line(Bank 1 Sensor1)
18
P0030 HO2S Heater Control Circuit(Bank 1 sensor 1)
19
P0031 HO2S Heater Control Circuit low (Bank 1 sensor 1)
20
P0032 HO2S Heater Control Circuit High (Bank 1 sensor 1)
21
P0136 O2 Sensor Circuit(Bank 1 Sensor2) signal error
22
P0137 O2 Sensor Circuit(Bank 1 Sensor2)
23
P0138 O2 Sensor Circuit High(Bank 1 Sensor2)
24
P0139 O2 Sensor Circuit slow response(Bank 1 Sensor2)
25
P0140 O2 Sensor Circuit Signal line short to heater line(Bank 1 Sensor2)
26
P0141 HO2S2 Heater Control Circuit(Bank 1 sensor 2)
27
P0037 HO2S2 Heater Control Circuit(Bank 1 sensor 2)
28
P0038 HO2S2 Heater Control Circuit(Bank 1 sensor 2)
29
P0171 System Too Lean
30
P0172 System Too Rich
31
P0201 Injector 1 Open Circuit
32
P0262 Injector 1 Short to Battery
33
P0202 Injector 2 Open Circuit
34
P0265 Injector 2 Short to Battery
35
P0203 Injector 3 Open Circuit
36
P0268 Injector 3 Short to Battery
