Revotron 1.2T
129
11. Fit the turbo heat shield mounted on support
bracket.
12. Fit the CCC support bracket near the cylinder
head cover.
13. Fit the rear support bracket for the closed
coupled catalytic convertor (CCC) near oil
sump.
viii. Fitment of Intake Manifold and
Peripherals
1. Fit the Spark Plugs by using Special Tool.
SPECIAL TOOL
Handle for Box Spanner -
2702 5890 06 13
Spark Plug Removing Socket -
2702 5890 06 20
2. Fit the Intake Manifold and Gasket to the
engine body and torque nuts to specified
torque.
