1.1 The position of Antirotation Earth terminal during fitment - Hold Terminal with antirotaion slot as shown below.
1.2 Locate the exact position of terminal on metal bracket / BIW.
1.3 Fix the tightening gun on nut with positioning of the earth terminal antilock in correct position as shown in fig.
1.4 Locate the tool & tighten the bolt with given torque by holding Earth terminal such that antirotation slot is as shown in fig.
1. Handling Method of Antirotation Earth Terminal
INFO FITMENT DRAWING FOR TAIL GATE
Electrical
BOLT / ZEST
