ELECTRICAL
130
MATING SIDE HARNESS 2 PINS CONNECTOR CON 5
PIN
NO
SIGNAL NAME
USED
SIGNAL
TYPE
ACTIVE
LEVEL
SIGNAL
DESTIN
-ATION
LOAD TYPE/
INPUT TYPE
BASE MID
1
Power Supply 3
Y
BATT
-
+VCC
-
X
√
2
-
-
-
-
-
-
X
X
NOTE:
Speed input be derived from instrument cluster speed output .Any changes regarding speed in the
instrument cluster may affect speed related functionality of BCM.
BCM FEATURES
SR.NO.
LIST OF FEATURES
BASE
MID
1
High security integrated audio system
√
√
2
Vehicle alarm system - Perimeter
√
√
3
Front fog lamps
√
√
4
Rear fog lamps
√
√
5
Front fog lamps as cornering lamps
X
√
6
Head lamp - Halogen low beam
X
√
7
Head lamp - Halogen high beam
X
√
8
Follow me home with RKE button
√
√
9
Follow me home with flash switch operated and automatic
X
√
10
Approach lights function (remote operated)
√
√
11
Position Lamps
√
√
12
Turn indicators
√
√
13
Hazard function
√
√
14
Three flash mode (turn tip)
X
√
15
Brake Lamps(CHMSL + rear brake lamps)
√
√
16
Reverse light control
X
√
17
DRL
X
√
18
Power Accessory Delay feature
√
√
19
Front wiper - intermittent operation (variable)
√
√
20
Vehicle Speed Sensitive wipe function
X
√
21
Front washer with drip wipe
√
√
22
Front wiper low speed /high speed /momentary operation
X
√
23
Rear wiper control one speed
√
√
24
Rear wiper fixed intermittent
X
√
25
Rear wash control
√
√
26
Automatic wiper with rain sensor (LIN Node)
X
√
