ELECTRICAL
121
D. Checking Pairing status:
In the EMS-ECU software select “Engine
Parameter 1”, then select “Electronic key” option
and click START. One window will pop-up &
shows below mentioned options. This window
gives the current status of immobilizer system.
i.e.
Immo Programmed:
Immobilizer enabled.
Vehicle Not Locked:
Vehicle ready for start.
Vehicle locked:
Vehicle will not start
Immo code programmed and locked:
Pairing operation OK. AES key is written in to
EMS and locked.
Immo code programmed and unlocked:
Pairing operation not done properly. AES key
is written in to EMS and Unlocked.
Key code OK / Authentication OK:
AES key
for EMS ECU and ICU are same.
Free starts Inactive:
After locking AES, free
starts are inactive. If AES is not locked free
starts is active for 5 times.
Immo CAN Communication OK:
Proper
communication. Otherwise it will show CAN
communication “OFF”.
