12.26.1 BCM CONNECTOR PIN SIGNALS APLICABILITY MATRIX:
MATING SIDE HARNESS 52 PINS CONNECTOR CON 1-BLACK
PIN
NO
SIGNAL NAME
USED
SIGNAL
TYPE
ACTIVE
LEVEL
SIGNAL
DESTIN
-ATION
LOAD TYPE/
INPUT TYPE
BASE
MID
1
Driver Door State
Y
Digital
Low
Input
WKUP I/P
√
√
2
Transport Link Signal
Y
Digital
High
Input
-
√
√
3
Door Latch Set Switch
Signal Driver
Y
Digital
Low
Input
WKUP I/P
√
√
4
Head Lamp ON Signal
Y
Digital
Low
Input
WKUP I/P
√
√
5
Wiper Rear park Signal
Y
Digital
Low
Input
-
√
√
6
Engine Start Stop Switch
Signal
Y
Digital
Low
Input
-
√
√
7
Turn Right Switch Signal
Y
Digital
Low
Input
-
√
√
8
Driver Door Unlock
Signal
Y
Digital
Low
Input
WKUP I/P
√
√
9
Ignition Key State IGN
Y
Digital
High
Input
WKUP I/P
√
√
10 Key IN Signal
Y
Digital
High
Input
WKUP I/P
√
√
11 Infotainment Removal Det
Y
Analog
-
Input
WKUP I/P
√
√
12 Wash Rear Switch Signal
Y
Digital
Low
Input
-
√
√
13 Wiper Rear Mode Switch
Signal
Y
Digital
Low
Input
-
√
√
14 Co-driver/Other Door
State
Y
Digital
Low
Input
WKUP I/P
√
√
15 Position Lamp Switch
Signal
Y
Digital
Low
Input
WKUP I/P
√
√
16 Door Latch Reset Switch
Signal Driver
Y
Digital
Low
Input
WKUP I/P
√
√
17 Spare1
Y
Digital
High
Input
-
√
√
18 Wiper Front Park Signal
Y
Digital
Low
Input
-
√
√
19 Turn Left Switch Signal
Y
Digital
Low
Input
-
√
√
20 Driver Door Lock Signal
Y
Digital
Low
Input
WKUP I/P
√
√
21 Ignition Key State CRANK
Y
Digital
High
Input
-
√
√
22 Brake Light Switch Signal
Y
Digital
High
Input
WKUP I/P
√
√
23 Ignition Key State ACC
Y
Digital
High
Input
WKUP I/P
√
√
24 Wash Front Switch Signal
Y
Digital
Low
Input
-
√
√
25 Wiper Front Switch Signal
Intermittent
Y
Digital
Low
Input
-
√
√
26 Crash Signal HW
Y
Digital
High
Input
-
√
√
