ELECTRICAL
128
MATING SIDE HARNESS 2 PINS CONNECTOR CON 3
PIN
NO
SIGNAL NAME
USED
SIGNAL
TYPE
ACTIVE
LEVEL
SIGNAL
DESTIN
-ATION
LOAD TYPE/
INPUT TYPE
BASE MID
1
Power Supply 2
Y
BATT
-
+VCC
-
√
√
2
Power Supply 1
Y
BATT
-
+VCC
-
√
√
MATING SIDE HARNESS 52 PINS CONNECTOR CON 4-BLUE
PIN
NO
SIGNAL NAME
USED
SIGNAL
TYPE
ACTIVE
LEVEL
SIGNAL
DESTIN
-ATION
LOAD TYPE/
INPUT TYPE
BASE MID
1
Wiper Front Low High
Relay Control
Y
Digital
Low
Output
Ext. Relay
X
√
2
Global Closing Signal
Y
PWM
High
Output
Signal
X
√
3
Cent Lock Internal
Switch Signal
Y
Digital
Low
Input
WKUP I/P
X
√
4
Bonnet State
Y
Digital
Low
Input
WKUP I/P
X
√
5
Rear Right Door State
Y
Digital
Low
Input
WKUP I/P
X
√
6
Low Beam Switch
Signal
Y
Digital
Low
Input
WKUP I/P
X
√
7
Wiper Front Low
Speed Signal
Y
Digital
Low
Input
-
X
√
8
Mirror Fold Unfold
Switch
Y
Digital
Low
Input
-
X
√
9
Smart Entry Wakeup
Signal
Y
Digital
High
Input
WKUP I/P
X
√
10
Spare3
Y
Digital
Low
Input
-
X
√
11
Auto Light ON Signal
Y
Analog
-
Input
-
X
√
12
CAN Body H
Y
CAN
-
BUS
-
X
√
13
CAN Body L
Y
CAN
-
BUS
-
X
√
14
Key Hole LED Control
Y
PWM
High
Output
LED
X
√
15
Tailgate State
Y
Digital
Low
Input
WKUP I/P
X
√
16
Cent Unlock Internal
Switch Signal
Y
Digital
Low
Input
WKUP I/P
X
√
17
Rear Left Door State
Y
Digital
Low
Input
WKUP I/P
X
√
18
Main Beam Switch
Signal
Y
Digital
Low
Input
WKUP I/P
X
√
19
Wiper Front High
Speed Signal
Y
Digital
Low
Input
-
X
√
20
Cockpit dimming
Signal
Y
Analog
-
Input
-
X
√
