ZEST AND BOLT - page 1095

ELECTRICAL
129
PIN
NO
SIGNAL NAME USED SIGNAL
TYPE
ACTIVE
LEVEL
SIGNAL
DESTIN
-ATION
LOAD TYPE/
INPUT TYPE
BASE MID
21 Crash Signal PWM Y PWM Low Input - X √
22 Wiper Rear Fixed
Internal Signal Y Digital Low Input - X √
23 ML Fail safe Switch
Signal Y Digital Low Input - X √
24 Spare4 Y Analog - Input - X √
25 LIN 2 Y LIN - BUS - X √
26 Battery GND3 Y GND - Ground - X √
27 - - - - - - X √
28 - - - - - - X √
29 - - - - - - X √
30 - - - - - - X √
31 - - - - - - X √
32 - - - - - - X √
33 - - - - - - X √
34 - - - - - - X √
35 - - - - - - X √
36 - - - - - - X √
37 - - - - - - X √
38 Roof Lamp LED Out Y PWM High Output LED X √
39 DRL Position Lamp
Control RH Y PWM High Output Bulb/LED X √
40 Head Lamp High
Beam Relay Y Digital High Output Ext. Relay X √
41 - - - - - - X √
42 - - - - - - X √
43 - - - - - - X √
44 - - - - - - X √
45 - - - - - - X √
46 - - - - - - X √
47 Mirror Fold Y Digital High/low Output Motor X √
48 Mirror Un Fold Y Digital High/low Output Motor X √
49 - - - - - - X √
50 Spare out1 Y PWM High Output Bulb/LED X √
51 Spot LED Out Y PWM High Output LED X √
52 DRL Position Lamp
Control Left Y PWM High Output Bulb/LED X √
