ELECTRICAL
45
INSPECTION OF HORN:
Connect the positive terminal of the horn to
battery (+) and negative terminal to battery (-). If a
clean and sharp sound is heard, the horn is OK. If
no sound is heard, check continuity of the horn
coil using a multimeter. If the coil is OK, check the
settings of the setting screw. Adjust the setting
screw till a clean and sharp sound is given out.
REFITMENT OF HORN:
1. Refit horn at its place.
2. Connect press Fit Horn Connector.
3. Refit front bumper.
HORN –TORQUE VALUE TABLE
APPLICATION
TORQUE
Horn MTG Bkt
0.95 to 1.0 Kgfm
