P1232 - 27:- BMS SOC jump fault - signal rate of change above threshold
Overview:
ISO Code
P1232 - 27
Customer Symptom
Vehicle will not crank
Fault Effects (On Vehicle)
No drive
No charging
Lamp Status (If Any)
HV fault on cluster
Fault occurrence scenario
Any operation
Normal Operating Condition
No fault
Probable Trouble Area
Software bug in BMS
Healing Condition
NA
System Details:
Battery SOC is estimated by the BMS and the value of the SOC is populated in diagnostics through DID
parameter
3402
.
Preliminary Checks:
1)
Ensure the vehicle is parked and not in charging.
2)
Ensure that the vehicle is in ignition ON condition.
Inspection Method:
Connect the tool and communicate to the battery pack as instructed through APPENDIX-C
Read DTC information of DTC ID –
P1232 - 27
Rectification Action:
1)
If DTC is appearing in real time, clear DTC information through service tool
2)
If DTC is not appearing in real-time but has only occurred before, store the snapshot data.
3)
Clear the DTC information on the respective DTC ID.
DTC’s confirmation:
After clearing, ensure the following points by referring to BMS DTC list.
1)
Read DTC ID –
P1232 – 27
for the existence of DTC information.
2)
If DTC still exists, reflash the battery pack using the service tool with the latest release SW available
in PLM database.
3)
Read DTC ID –
P1232 – 27
for the existence of DTC information post flashing.
4)
If DTC still exists, the HV battery pack component has to be replaced as instructed by the respective
ECU replacement guide
Component Location & Image;Connector Location; Connector View & Information: -
APPENDIX-A
