P1229 - 1A:- BMS insulation fault first level alarm - circuit resistance below threshold
Overview:
ISO Code
P1229 - 1A
Customer Symptom
NA
Fault Effects (On Vehicle)
NA
Lamp Status (If Any)
HV Fault alarm on cluster
Fault occurrence scenario(In the order of
probability)
Water Ingress
Normal Operating Condition
No fault
Probable Trouble Area
Insulation damage in HV sytem
Healing Condition
NA
System Details:
Battery insulation is moniterd by the BMS through the insulation monitoring device. Pack insulation can
fail due water ingress.
Preliminary Checks:
Inspection Method:
Connect the tool and communicate to the battery pack as instructed through APPENDIX-C
Read DTC information of DTC ID –
P1229 – 1A
Rectification Action:
1)
If DTC is appearing in real time, clear DTC information through service tool
2)
If DTC is not appearing in real-time but has only occurred before, store the snapshot data.
3)
Clear the DTC information on the respective DTC ID.
DTC’s confirmation:
After clearing, ensure the following points by referring to BMS DTC list.
1)
Read DTC ID –
P1229 – 1A
for the existence of DTC information.
2)
If DTC still exists, reflash the battery pack using the service tool with the latest release SW available
in PLM database.
3)
Read DTC ID –
P1229 – 1A
for the existence of DTC information post flashing.
4)
If DTC still exists, the HV battery pack component has to be replaced as instructed by the respective
ECU replacement guide
Component Location & Image;Connector Location; Connector View & Information: -
APPENDIX-A
