BODY
51
5. Remove Side Valence cover Assembly to
access side mounting of front fender.
6. Pull out Front Fender cladding Assy.
7. Remove mounting on fender bracket.
8. Open the Bonnet.
9. Remove two top mounting screw on side
plenum cover and Pull out Side Plenum Cover.
10.Remove front wheel arch liner. (For procedure
refer front wheel arch liner removal process.)
11.Remove lower mounting screw.
12.Remove front Bumper. (For procedure refer
Front Bumper removal process.)
13.Loosen and remove head lamp mounting
screws.
14.Loosen headlamp "Inner Mounting".
