LV ELECTRICAL SYSTEM
66
17.IGNITION KEY (If Applicable)
1. FLIP KEY WITH REMOTE
FUNCTIONAL DETAILS
1. Unlocking all doors.
2. Approach light/ Tailgate opening
3. Locking all doors
4. Folding key blade in/out
1. Unlocking all doors
Pressing the unlock push-button (1) of remote will
unlock all the Doors.
2. Approach light
Press approach light button (2) once, low beam,
position, roof lamp will turn ‘ON’.
This feature helps to find and reach the parked
vehicle or to reach home in dark/ cloudy condition
after parking. Red LED will be flash on the
remote. To switch ‘OFF’ the approach lights,
press and re- lease the same button or it
automatically turns ‘OFF’ after certain time.
Tailgate Unlatch
To unlatch the Tail gate, long press the approach
light button (2) on remote for more than 2 sec.
NOTE
Tailgate once unlatched will not get lock
automatically with will locked by slamming
it
3. Locking all doors
Pressing the Lock push-button (3) once.
Remote locks all the doors of the vehicle.
4. Folding key blade IN / OUT
Press button (4) to flip out the key blade.
For folding, press the button (4) and fold the key
blade inside.
NOTE
Key Blade should not be fold without pressing the
button. In addition, it should not be force in any
direction apart from folding direction to avoid
damage to Flip Mechanism
Flip key Features
Vehicle search
In vehicle locked condition if lock button on
remote key is pressed the turn indicators of
vehicle flashes 4 times.
Automatic activation of immobilizer
If key is removed from ignition, the engine will be
immobilized automatically even if you forget to
lock the vehicle.
For few variant, Ignition off is required to
immobilize the vehicle.
Auto locking / unlocking of doors / auto relock
• Vehicle doors get automatically locked when
all doors are closed and the vehicle speed
crosses 10 kmph. Please refer section starting
and driving for more information.
• When ignition key is taken out all the doors,
get automatically unlocked.
