LV ELECTRICAL SYSTEM
64
15.DOOR HANDLE SWITCH
REMOVAL
1. Disconnect the battery.
2. Remove the Door Handle.
(Refer Door Handle
Removal Procedure in the Body Section).
3. Unscrew the door handle cover with dedicated
screw panel.
4. Remove door handle switch wire harness fitted
in the handle.
5. Remove the door handle switch with wire
harness.
6. Similarly follow the above steps for other door
handle switches on the door.
REFITMENT
For refitment follow the procedure in reverse.
NOTE
1. Ensure that door handle switch connector is
fitted tightly and properly.
2. After replacing the door handle switch, check
vehicle locking/ unlocking state changes by
pressing the replaced door handle switch.
3. The smart key shall be present during door
handle switch press.
4. Connect the Diagnostics tool and clear the
DTCs.
