LV ELECTRICAL SYSTEM
58
13.POWER WINDOW SWITCHES & INHIBIT SWITCH
Window winding switches are used to move the window glasses Up& Down.
Driver door window winding switch includes all door power window switches & inhibit switch (child safety).
Inhibit Switch - Red indication on inhibit switch indicates that operation of glass from individual power window
switch (mounted on respective door trim) is allowed (valid for co- river and both rear doors)
No indication on inhibit switch indicates that operation of glass from individual switch (mounted on respective
door trims) is inhibited.
Only Driver door window is provided with Auto down feature & is time based.
A. LOCATION
Window winding switches are provided on RH
side front door. Separate individual switch is
provided on front door LH & rear RH / LH doors.
The switch will function when ignition key is turned
to ‟ON‟ position.
For taking window glass “UP”, Pull the knob. And
for window glass “Down”, Push the knob .
Do not press switch further when window glass is
at its extreme position.
Do not operate window glass frequently,
otherwise Window winding motor may get over
heated and stop working till it cools down.
