BODY
46
1.4.32
“C” PILLAR TRIMS
1. Remove rear seat (for removal process refer
rear seat removal process).
2. Remove rear seat belt (for removal process
refer seat belt removal process)
3. Remove rear quarter trim. (for removal
process refer rear quarter trim. removal
process)
4. Pull out cap
5. Remove mounting screw and pull out trim
FITMENT
For fitment follow reverse procedure of removal.
1.4.33 GRAB HANDLE:
NOTE
The procedure given for removal of grab handle is
applicable for all three grab handles in the vehicle.
REMOVAL
1. Open the flap of the grab handle.
2. Remove two mounting screws and remove the
grab handle.
FITMENT
For fitment follow reverse procedure of removal.
