6F33 TRANSAXLE
8
4. GENERAL INFORMATION
A. MECHANICAL SYSTEM
B. OPERATION COMPONENTS AND FUNCTION
OPERATING SYSTEM
SYMBOL
FUNCTION
Over Drive Clutch
ODC
Connect the input shaft with the
rear planetary carrier
3-5-Reverse Clutch
35RC
Connect the input shaft with the
mid sun gear
2-6 Brake
26B
Hold the mid. sun gear
Low-Reverse Brake
LRB
Hold the rear carrier
Under Drive Brake
UDB
Hold the front sun gear
One way clutch
OWC
Control the rotational direction of
the rear carrier
