108 / 745
KRYOTEC ENGINE
100
13. Install the battery (Refer to 08 -
Electrical/Battery System/BATTERY/Removal and
Installation).
14. Install the engine cover (Refer to 09 -
Engine/COVER, Engine/Removal and Installation).
15. Install the left and right half shafts (Refer to 03
- Differential and Driveline/Half Shaft/Removal and
Installation).
16. Fill the engine oil.
17. Install the front suspension crossmember
(Refer
to
13
-
Frame
and
Bumpers/Frame/CROSSMEMBER,
Front
Suspension/Removal and Installation).
18. Install the front fascia (Refer to 13 - Frame and
Bumpers/Bumpers/FASCIA, Front/Removal and
Installation).
19. Install the front wheel splash shields (Refer to
23 - Body/Exterior/SHIELD, Splash/Removal and
Installation).
20. Install the front belly pan (Refer to 13 - Frame
and Bumpers/Under Body Protection/BELLY
PAN/Removal and Installation).
21. Install the front wheels (Refer to 22 - Tires and
Wheels/Removal and Installation).
F. VIBRATION DAMPER
REMOVAL
1. Raise and support the vehicle (Refer to 04 -
Vehicle Quick Reference/Hoisting - Standard
Procedure).
2. Remove the right front tire and wheel assembly
(Refer to 22 - Tires and Wheels/Removal and
Installation).
3. Remove the right front wheelhouse splash shield
(Refer
to
23
-
Body/Exterior/SHIELD,
Splash/Removal and Installation).
4. Remove the serpentine belt (Refer to 07 -
Cooling/Accessory
Drive/BELT,
Serpentine/Removal and Installation).
5. Remove the bolts (1a) and the vibration damper
(1b).
FITMENT
1. Install the vibration damper (1a). Tighten the
bolts (1b) to the proper (Torque Specifications).
2. Installed the serpentine belt (Refer to 07 -
Cooling/Accessory
Drive/BELT,
Serpentine/Removal and Installation).
