SUSPENSION
30
3. Ensure that oil seal in transaxle is not damaged
while fitting drive shaft.
PRECAUTION:
Use a new hub bearing and new circlip, oil the
bearing housing in knuckle carrier and hub itself.
Old bearing, even if serviceable cannot be reused.
SUB ASSEMBLY - KNUCKLE / HUB:
Clean all the parts thoroughly and replace damage
/ worn out parts.
1. With the help of drift part No. 2779 5890 3301
and 2640 5890 3511 fit bearing in the knuckle
2. Fit circlip.
3. Place the knuckle assembly over the hub. Using
drift part No. 2576 5890 4401 press the knuckle
assembly on the hub.
