1.5L REVOTORQ BS VI ENGINE
162
13. Apply sealant to the cover as shown.
14. Install the crankshaft oil seal cover.
15. Fit the crankshaft oil seal.
SPECIAL TOOL
Drift crankshaft rear cover oil seal -:
2702 5890 06 08
iv. FITMENT OF CYLINDER HEAD ON
CYLINDER BLOCK
1. Place the Cylinder Head gasket as shown.
NOTE
Ensure that the "TOP" mark on the gasket
is facing towards the intake manifold side
of the block.
Refer ‘Assembly Clearances’ section for selection
table.
