1.5L REVOTORQ BS VI ENGINE
165
vi. FITMENT OF TIMING BELT
1. Install the flywheel using mounting bolts and
locator pin.
2. Lock the flywheel using locking pin.
3. Apply sealant, install gasket and the oil pump
assembly.
4. Install the crankshaft oil seal.
SPECIAL TOOL
Drift (Oil seal in Pump) -:2702 5890 18 01
5. Using the mounting bolt install the crankshaft
gear by applying specified torque.
6. Install the rear timing cover.
