1.5L REVOTORQ BS VI ENGINE
100
36. Remove the “A” mount assembly.
37. Remove the “C” mount assembly and the
rubber stopper.
38. Now move the two post lift upwards and place
the support stand, under the engine. (Use a
suitable wooden block or other support for
additional height as necessary.)
SPECIAL TOOL
Engine Support stand -:
5438 5890 2402
39. Now slightly lower the lift until engine and
transaxle assembly is securely placed / fix on
the support stand.
40. Disconnect the lifting crane from the engine.
CAUTION
Take care when raising the vehicle off the engine
and transaxle assembly. Verify all components
and electrical connections are disconnected prior
to raising the vehicle, or vehicle damage occurs.
41. Now carefully move the lift up.
42. Take out the engine and transaxle assembly
along with support stand.
