1.5L REVOTORQ ENGINE
51
iii. COOLANT FILLING (DE – AREATION
PROCEDURE)
METHOD 1
Using Radiator Check and Fill system Kit.
NOTE
Prior to start the process, drain and flush
coolant system.
Kit Radiator check & Fill System (8855 WORK
0087)
1. Take the specified premixed coolant in a
clean container preferable having measuring
scale, approximately 10% more than the
specified coolant capacity of the vehicle (e.g.
if the coolant capacity is 6 ltr then take 6.6 ltr).
2. Connect pneumatic line using commercially
available suitable QRC. Install the cone
adapter from the kit to the vacuum gun and.
Put the coolant filler hose into the coolant
container; ensure that the filler hose will
always be submerged.
3. Insert the cone adapter with vacuum gun into
the radiator filler neck (no loss tank) or
coolant aux tank; make sure the refill hose
valve is closed.
