1.2L REVOTRON ENGINE
152
X. Assembly of Intake Manifold
1. Install the intake manifold as per specified
torque sequence.
2. Install the bottom support bracket to the intake
manifold.
3. Fit the fuel injectors on the fuel rail.
4. Tighten the mounting bolts of the injector
retainer on the fuel rail.
5. Install the fuel rail along with the injectors.
6. Install the temperature pressure sensor on the
intake manifold.
