1.2L REVOTRON ENGINE
153
7. Install all the support brackets on the intake
manifold.
8. Install the electronic throttle body.
9. Fit the purge valve.
10. Install the EVRV hose and its support bracket
mounted on the head cover.
11. Connect all the hoses between purge valve
and the intake manifold.
12. Remove the engine assembly from the bench
suitably.
