Deactivation Procedure:
To de-activate the system, disengage the reverse
gear. "The system can also be deactivated
through cross icon on infotainment screen if it was
activated through infotainment screen."
NOTE
1. While Park Assist is running, doing Ignition
OFF will switch OFF the Park Assist
functionality.
2. Before Ignition OFF, if reverse gear is already
engaged then if you do Ignition ON, Park
Assist will start automatically.
There is no way to permanently disable Park
Assist feature in the vehicle.
Park Assist Audio Settings:
To change Park Assist audio settings related
options, you have to do following sequence of
operations.
Go to
“Set Up -> Vehicle Setup -> Park Assist ->
Tone volume
Park Assist Volume Setting:
Increase or decrease volume by tapping
⊖
or
⊕
symbols on the infotainment music system touch
screen.
Mix With Audio
By default, Park Assist volume is mixed with
infotainment system audio. “Mix with Audio“ option
allows you to enjoy music even when park assist
is active. With this option, Park Assist warning
tone and media tone are smartly mixed together in
such a manner that park assist warning tone
sounds louder than media tone when park assist
is active.
Park Assist Tone
You can select 3 different types of Park Assist
tones. To change any tone you have to following
sequence of operations,
“Set Up -> Vehicle Setup -> Park Assist -> Park
Assist Tone“
Park Assist Delay Timer:
If Park Assist system is deactivated by “Reverse
Gear”, it will take certain configurable time period
to go to previous infotainment screen. This is to
ensure that, Pak Assist should not switch off
immediately for repeated engagements /
disengagements of reverse gear.
You can configure this delay time period by the
following sequence of operations,
“Set Up -> Vehicle Setup -> Park Assist -> Park
Assist Delay Timer”
HMI Indications:
In case of park assist fault or malfunction,
following screens may appear on the infotainment
music system.
Ultrasonic System Faulty:
Reasons for this fault may be
a. Sensor malfunction
b. Partner components such as Infotainment
music system, Instrument Cluster or Body
Control Module failure.
⚠
If you see below
screen on Infotainment music system display,
please contact TATA dealer for rectification.
