ELECTRICAL
35
9. Remove the bulb holder from lamp.
10. Remove/replace the bulb.
11. Rotate the bulb holder in clockwise to lock the
bulb holder on lamp.
Removal of tailgate tail lamp.
12. Open tail gate.
13. Pull out the trunk trims.
14. Disconnect electrical connection of tail lamp.
15. Loosen and remove the mounting two-cap
nut.
16. Pull the Lamp Outside (-X Axis) Disengaging
From Catcher.
REFITMENT
Follow the removal procedure in reverse.
