SUSPENSION
42
10 SUSPENSION PRE-LOADING CONDITION.
1. After working on any of the following fasteners,
do not apply complete torque. Just do the
partial or hand tightening. Ensure that no
clamping torque applied.
a) LCA front bush fastener
b) RTB Pivot mounting fasteners
c) Rear Shock absorber bottom mounting
fastener.
2. Park vehicle on pit.
3. Load the vehicle with two persons in front and
one in rear such that one person on driver and
co-driver seat each and one person on rear
seat in center of seat. The weight of the person
seating should be between 70Kg to 80Kg.
NOTE:-
Loosen the fasteners partially ensuring that no
clamping torque applied and bolt is not disengaged
from nut.
4. Rumble the vehicle suitably
5. Tighten the bolt with the specified torque.
