DRIVESHAFT -
DIESEL
12
5. Insert the LCA ball joint in knuckle & tighten
the mounting fastener with torque 5.5 Kg-m.
6. Insert the steering Link ball joint into knuckle
& tighten the nyloc nut with torque 6.6 kg-m.
7. Use allen Key and Tighten Upper ARB Link
on to the Front Strut with Torque value 7 ± 0.5
Kg-m.
8. Apply Brake and Tighten Drive shaft Lock
Nut.
9. Fix Mud liner front RH.
10. Tighten wheel nuts and Fix Front wheel.
11. Fix Wheel Cap.
