TRANSAXLE - TA65 Star
28
26. Remove the top cover assembly.
27. Remove Neutral Speed Sensor.
28. Remove the hex flanged bolts on the housing
.
29. Rotate the transaxle upside down. Remove the
hex flange bolts provided at clutch housing.
30. Remove the gear box housing (rear half) by
gently tapping with a mallet.
31. Remove reverse idler shaft, & Reverse lower
bracket Assembly.
32. Remove reverse idler gear assembly.
33. Remove the adaptor part no. 2702 5890 2611
for locking input shaft. Tap the input shaft
gently from the spline end also top the lay
shaft.
