TRANSAXLE - TA65 Star
27
19. Remove the conical washer.
20. Remove the 5th gear (input shaft).
21. Remove lock plate (lay shaft bearing) from
housing rear half by unscrewing T40 torx head
screws.
NOTE:
Use new torx head screws during
reassembly
22. Remove lock plate input shaft bearing from
housing (rear half) by unscrewing the screws.
23. Remove the hex flanged bolts on housing.
24. Remove the filler plug on the housing
.
25. Remove the Drain plug on the housing
.
