217 / 1119
1.5L REVOTORQ ENGINE
29
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
25
Hex Bolt (Cyl. Head) (Qty. 10)
5.0 + 180°
26
Gear Camshaft (Intake)
27
Gear Camshaft (Exhaust)
28
Locating Pin (Qty. 2)
29
Camshaft Bearing Cap (Thrust) (Qty. 2)
30
Hex. Flange Bolt M6x35 (Qty. 10)
1.5
31
Camshaft Brg. Cap (Rear)
32
Hex. Bolt (Camshaft Brg. Cap) (Qty. 2)
1.5
33
Camshaft Position Sensor
34
Hex. Flange Screw M6x16
0.4+0.1
35
Assy. Vacuum Pump
36
Hex. Flange Screw M6X20
1.5
NOTE
•
This Symbol indicates critical tightening torque.
