1.2L REVOTRON ENGINE
96
CANISTER
REMOVAL
1. Remove air filter assembly.
2. Relieve fuel pressure.
3. Disconnect canister hoses.
4. Slide the canister in upward direction and take
out from firewall bracket.
FITMENT
For fitment follow reverse procedure for removal.
CANISTER PURGE VALVE
REMOVAL
1. Relieve fuel pressure.
2. Disconnect electrical connection of the
canister purge valve.
3. Disconnect hoses to the canister purge valve.
4. Loosen the mounting brackets bolts and
remove canister purge valve.
FITMENT
For fitment follow reverse procedure for removal.
