ELECTRICAL
43
4. Pull the lamp at Rear bumper to release from
take lamp out from vehicle
NOTE
REAR FOG LAMP (IF APPLICABLE)
1. Refer Reverse lamp for Removal
Procedure
4.9 DRL
The DRL are located in the lower part of the front
bumper.
REMOVAL:
1. Refer Front bumper for Removal Procedure.
2. Disconnect the electrical connection of DRL
lamp.
3. Remove the screw mounting fastener.
4.
Pull the DRL at Front bumper to release from
take lamp out from vehicle.
REFITMENT:
For refittment follow the procedure in reverse.
