ELECTRICAL
41
REMOVAL AND REFITMENT OF TAIL LAMP
REMOVAL
1. Remove and pull out the cap
2. Remove the nut holding the lamp and pull out
the lamp.
3. Unlock side indicator lock in anticlockwise
direction & Remove front direction indicator
bulb.
4. Remove the nut holding the lamp and pull out
the Tail position trunk Lid side lamp.
