ELECTRICAL
17
REMOVAL AND REFITMENT OF HEAD LAMP:
REMOVAL
1. Open engine hood & ensure all lamps are in
OFF condition.
2. Remove front bumper. Refer "Removal & Re-
fitment of Front bumper" from Body Section.
3. Disconnect head lamp connectors.
4. Loosen head lamp two top mounting fasteners.
5. Loosen head lamp "Inner Mounting" & side
fastener.
6. Hold head lamp properly and remove it.
REFITMENT:
1. Position head lamp to its proper place.
2. Refit head lamp Inner fastener. (One No.)
3. Refit head lamp top fasteners. (Two No.)
4. Connect head lamp connection.
5. Refit front bumper.
