KRYOTEC ENGINE
69
A. FUEL RAIL
REMOVAL
1. Disconnect battery’s negative terminal
2. Remove the air filter and resonator assembly.
3. Remove Engine cover.
4. Disconnect electrical connection to fuel rail
sensor.
5. Disconnect the fuel pressure line of the fuel rail.
NOTE
Components not to be reused.
6. Loosen and remove the H.P. fuel lines
connecting fuel rail and the fuel injectors.
NOTE
Components not to be reused.
7. Loosen and remove mounting bolts and take
out the fuel rail assembly.
FITMENT
For fitment follow removal procedure in reverse.
