Q501 4 Cylinder MT Application

DTC Troubleshooting Data

Version: 0.1

Date: 21-Sep-2018

Prepared By: Mithi Prasad, Sarang Kulkarni, Manish Gupta

Checked By: Yogesh Jadhav

Approved By: Satish Kumar P

Page: 932 of 1052

Copyright ©

TATA MOTORS Ltd.

This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.

P0830-62: Clutch Pedal Switch “A” Circuit – Plausibility check for Clutch

Overview:

DTC Description (User Friendly)

Two digital clutch switches not plausible

ECU Pin Number

K052, K012

Customer Symptom

CEL ON, Cruise Control will be disabled

Fault Effects (On Vehicle)

Cruise Control will be disabled

Lamp Status (If Any)

MIL OFF, CEL ON

Fault Detection Condition (Root cause)

If EMS detects a Gear Change without Clutch top travel input

transition (5 Sec before or after the gear change) then this

fault gets logged

Normal Operating Condition

During every gear change, EMS detects a transition in Clutch

Top Travel switch

Probable Trouble Area

WH connections between EMS ECU and Clutch Pedal sensor

connector.

Clutch position sensor

EMS ECU

Healing Condition

Rectify the error

Clear through diagnostic tool

Ignition OFF & ON

Component Details:

Clutch position sensor is a hall effect based sensor which provides two digital inputs to EMS ecu. First input is top travel

input – which implies clutch pedal is pressed 40% another input is Clutch bottom travel input – which implies clutch pedal

is pressed 90%.

Clutch 40% input will be used for Vehicle drivability refinements and Clutch 90% input will be used for Vehicle start, CGD

and GSI functions.

Preliminary Checks:

1. Check whether the customer voice / view about the issue is matching with the fault effects mentioned above. If

yes, go ahead with next steps. If not, check for other DTC’s presence.

2. Check whether similar complaints are earlier reported. If yes, perform the preliminary checks with respect to

earlier issue closure.

3. Check for any other faults presence related to ECU Internal power supplies; Follow rectification process for those

faults, before proceeding further.

4. Check for Wiring Dis-continuity between Clutch position sensor & EMS ECU. If found, fix them

5. Check whether the Clutch top travel input to ECM is open circuited.

6. Check whether the Clutch position sensor is receiving power supply and ground.

Trouble Shooting:

Step Checks

IF YES

IF NO

1.

Check the wiring harness continuity between ECM pin

K052 and Clutch position sensor pin 3

Check the wiring harness continuity between the ECM pin

Go to next step

Rectify / Repair

harness

connections
