P245D-12: EGR cooler bypass control Circuit High Bank 1 – EGR high pressure cooler bypass command (circuit

short to battery)

Overview:

DTC Description (User Friendly)

EGR high pressure cooler bypass command (circuit short to

battery)

ECU Pin Number

A069

Customer Symptom

Increased fuel consumption, Poor Engine performance, If

vehicle operated for long with fault, Engine components might

be damaged.

Fault Effects (On Vehicle)

Increased fuel consumption.

Lamp Status (If Any)

MIL OFF CEL OFF

Fault Detection Condition (Root cause)

ECM pin A069 Shorted to Battery

Normal Operating Condition

No Fault

Probable Trouble Area

Wiring Harness connections btw EGR cooler by pass valve

pin 2 and ECM pin k090

EGR cooler bypass valve pin 1 not receiving 12 V supply

EGR Cooler by pass valve

EMS ECU faulty

Healing Condition

Rectify the error

Clear through diagnostic tool

Ignition OFF & ON

Component Details:

EGR cooler bypass valve is a solenoid valve, which controls the flow of EGR air through EGR

cooler based on EGR cooler load and Exhaust gas temperature. EMS ECU controls the valve opening from 0% to 100%

through PWM command to valve.

Preliminary Checks:

1. Check whether the customer voice / view about the issue is matching with the fault effects mentioned in above

Table. If yes, go ahead with next steps. If not, check for other DTC’s presence.

2. Check whether other customers report similar complaints earlier. If yes, perform the preliminary checks with

respect to earlier issue closure.\

3. Loose/ Damaged Connections between EGR cooler by pass valve and EMS ECU.

4. Loose/ Damaged Connections between EGR cooler by pass valve and Main relay supply.

5. Check for damage of pins or back out of pins at ECU connector / EGR cooler by pass valve connector.

Trouble Shooting:

Step Checks

IF YES

IF NO

Check Whether the EGR cooler bypass valve is installed

on Vehicle

Go to Next Step

Fit EGR cooler

bypass valve

Check for any mechanical damage in EGR cooler bypass

valve

Replace EGR cooler

bypass valve

Go to next step

Is there wiring harness electrical continuity between ECU

pin A069 & valve pin 2. Also Check continuity between the

Main Relay supply and the valve pin 1.

Go to next step

Rectify the wiring

harness

connections as per

the circuit
