P0532-12: A/C Refrigerant Pressure Sensor "A" Circuit Low: Indicates an error when the compressor pressure is

above a certain upper limit

Overview:

DTC Description (User Friendly)

A/C Refrigerant Pressure Sensor "A" Circuit Low: Indicates an

error when the compressor pressure is above a certain upper

limit.

ECU Pin Number

A043 – 5V supply to A/C Refrigerant pressure sensor

A044 – Input analog signal to EMS ECU.

A048 – Gnd signal to A/C Refrigerant pressure sensor

Customer Symptom

MIL OFF, CEL OFF

Fault Effects (On Vehicle)

Lamp Status (If Any)

Fault Detection Condition (Root cause)

This fault gets logged if the AC pressure sensed by EMS ECU

is less than 2 bar.

Normal Operating Condition

AC refrigerant pressure will be in the range of 2 to 30 bar.

Probable Trouble Area

Wiring harness connections between EMS and AC pressure

Sensor , AC pipes damaged, AC gas not filled in, EMS ECU.

Healing Condition

Rectify the error Clear through diagnostic tool.

Ignition OFF & ON

Component Details:

The air conditioning system is pressurized with a gas known as a refrigerant. The refrigerant flows through the lines in the

air conditioning system to remove heat and moisture from the interior of your vehicle. It circulates it through the

condenser, which disperses the heat into the air. The refrigerant is pressurized in the air conditioning system to operate

properly, and it is monitored by the refrigerant pressure sensor. Based on the AC refrigerant pressure, EMS controls the

AC Compressor and Cooling Fans.

Preliminary Checks:

1. Check whether the customer voice / view about the issue is matching with the fault effects mentioned in

above Table. If yes, go ahead with next steps. If not, check for other DTC’s presence.

2. Check whether other customers report similar complaints earlier. If yes, perform the preliminary checks with

respect to earlier issue closure.

3. Check for Damage in EMS ECU connector / A/C Refrigerant pressure sensor.

4. Check for any back out of pins at EMS ECU connector / A/C Refrigerant pressure sensor.

5. Check for any damage of pins at EMS ECU connector / A/C Refrigerant pressure sensor.
