P049D-22: EGR “A” Control Position Exceeded Learning Limit – EGR high pressure valve positive position

deviation (signal above upper limit)

Overview:

DTC Description (User Friendly)

EGR high pressure valve positive position deviation (signal above

upper limit)

ECU Pin Number

A067, A088, A040, A079, A078

Customer Symptom

MIL ON, CEL OFF. Increased fuel consumption

Fault Effects (On Vehicle)

Decreased Engine Performance, Increased fuel consumption.

Lamp Status (If Any)

MIL ON, CEL OFF

Fault Detection Condition (Root cause)

Positive control deviation is detected if control deviation > 11.99

Normal Operating Condition

No fault

Probable Trouble Area

EGR valve fouled

EGR Valve

Healing Condition

Rectify the error

Clear through diagnostic tool

Ignition OFF & ON

Component Details:

An incomplete burnt gas in exhaust is return to the cylinder. EGR works by recalculating a portion of an engine's

exhaust gas back to the engine cylinder. Intermixing the incoming air with recalculated exhaust gas dilutes the mix with

inert gas and in turn reduce the combustion temperatures for reducing NOx emissions.

Preliminary Checks:

1. Check whether the customer voice / view about the issue is matching with the fault effects mentioned in above

Table. If yes, go ahead with next steps. If not, check for other DTC’s presence.

2. Check whether other customers report similar complaints earlier. If yes, perform the preliminary checks with

respect to earlier issue closure.\

3. Check for any leakages in EGR flow path.

4. Check whether the EGR valve is physically damaged

5. Check whether the EGR valve is fouling with any other component.

6. Check for damage of pins at ECU connector.

Trouble Shooting:

Step Checks

IF YES

IF NO

Run the EGR High Pressure DC Motor Test Routine. Is the

Routine Result – OK?

Go to Next Step

Rectify the wiring

Harness

connections

between EGR

Valve and EMS

ECU. Repeat the

Routine Test again.

If the Routine result

is negative, then

call hotline for
