Circuit Schematic:
EMS ECU
VGT Actuator H Bridge (-)
A25
VGT
Actuator
&
VGT
Position
Sensor
02
VGT Position Sensor Supply
A39
05
VGT Position Sensor Signal
A77
04
VGT Position Sensor Ground
A76
03
VGT Actuator H Bridge (+)
A03
01
Component Location & Image:-
NA
Connector View & Information: -
