Trouble Shooting:
Step Checks
IF YES
IF NO
1.
Is there any rust/oxidization observed on Sensor Terminals.
Clean the Rust or
repair or replace
Go to Step 2.
2.
Check the continuity between the EMS ECU pin A03 and
Batt ground. If continuity is there then short to ground.
Establish continuity
by rectifying wiring
harness connections
as per the
schematic.
Go to Step 3.
3.
Are there any pins damaged at Sensor/EMS ECU
Connector.
Replace the
connector or wiring
Harness.
Go to step 4.
4.
Are there any pins backed out from the Sensor/EMS ECU
Connector.
Rectify/Replace
Connectors.
Go to Step 5.
5.
Is Sensor pin 4 short circuited to GND/Battery or
Open?
Repair the harness
as per the
schematic.
Go to Step 6.
6.
Is sensor physically Damaged?
Replace Sensor.
Go to Step 7.
7.
If fault still persists.
then replace sensor
and if fault still
persists then call
Hotline.
Follow the above
procedure again for
Reconfirmation.
DTC’s confirmation
(checks before handing over vehicle to customer)
:
1. Check the errors at Ignition ON, engine running @ Idle & Fly-up with different vehicle speeds also.
2. If error present, then rectify the errors.
3. Confirm that there is no error logged in EMS before handing over vehicle to customer.
