Q501 4 Cylinder MT Application
DTC Troubleshooting Data
Version: 0.1
Date: 21-Sep-2018
Prepared By: Mithi Prasad, Sarang Kulkarni, Manish Gupta
Checked By: Yogesh Jadhav
Approved By: Satish Kumar P
Page: 567 of 1052
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
Circuit Schematic:
EMS ECU
VGT Actuator H Bridge (-)
A25
VGT
Actuator
&
VGT
Position
Sensor
02
VGT Position Sensor Supply
A39
05
VGT Position Sensor Signal
A77
04
VGT Position Sensor Ground
A76
03
VGT Actuator H Bridge (+)
A03
01
Component Location & Image:-
NA
Connector View & Information: -
