Immobilizer –DTC Troubleshooting Data

Version: 1.

2

Date:

03-June-2014

Prepared Author

:

Sarang K/Mithipati P

Review & approved by

: R A Rode (ERC-E&E)

Page: 10 of 67

Copyright ©

TATA MOTORS Ltd.

This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.

B1636-81: Vehicle Immobilizer Control Module Communication with transponder- invalid serial data

received.

Overview:

ISO Code

B1636-81

DTC simple description

Incorrect transponder key

Customer Symptom

Vehicle cannot be started.

Fault Effects (On Vehicle)

Vehicle cannot be started.

Lamp Status (If Any)

Immo status lamp On

Fault Detection Condition

At ignition On

Normal Operating Condition

Authentication between EMS & Immo is successful

Probable Trouble Area

Immobilizer, transponder key (E-Key)

Healing Condition

Component Details:

Immobilizer system is designed to prevent vehicle theft by electronically disabling the engine starting system. The

engine can be started only with vehicle’s original immobilizer ignition key, which has an electronic identification

programmed code. Immobilizer unit (ICU) is an add-on part on the ignition switch, fitted on the steering column.

The engine can be started only with the vehicle’s original immobilizer ignition key. The electronic key

communicates the identification code to ICU when the key is turned to the "Ignition ON" position.

Preliminary Checks:

Check ignition On with correct transponder key .

Trouble Shooting:-

Step Checks

IF YES

IF NO

1.

Check the number of key learnt with immo =2

Go to next step

Use correct

transponder key

2

Replace key with new matching to ignition lock, pair with

immobilizer

Go to next step

3

Replace immobilizer with new good one, pair with EMS

DTC’s confirmation:-

After the DTC clearing, vehicle should be start & no error in immobilizer.

Circuit Schematic Diagram:

Refer the immobilizer schematic

VICM

pin

no

Pin description

1

Vbatt (KL30)

2

GND

3

CAN_H(High-speed)

4

Ignition (KL15)

5

Status LED

6

Trasport Mode Fuse (10A)
