Immobilizer –DTC Troubleshooting Data

Version: 1.

2

Date:

03-June-2014

Prepared Author

:

Sarang K/Mithipati P

Review & approved by

: R A Rode (ERC-E&E)

Page: 8 of 67

Copyright ©

TATA MOTORS Ltd.

This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.

B1636-31: Vehicle Immobilizer Control Module Communication with transponder No signal

Overview:

ISO Code

B1636-31

DTC simple description

Immobilizer communication failed with transponder

Customer Symptom

Vehicle cannot start

Fault Effects (On Vehicle)

Vehicle cannot start

Lamp Status (If Any)

Immo status lamp ON

Fault Detection Condition

At ignition On

Normal Operating Condition

Authentication between EMS & Immo is successful

Probable Trouble Area

Immobilizer, transponder key

Healing Condition

Component Details:

Immobilizer system is designed to prevent vehicle theft by electronically disabling the engine starting system. The

engine can be started only with vehicle’s original immobilizer ignition key, which has an electronic identification

programmed code. Immobilizer unit (ICU) is an add-on part on the ignition switch, fitted on the steering column.

The engine can be started only with the vehicle’s original immobilizer ignition key. The electronic key

communicates the identification code to ICU when the key is turned to the "Ignition ON" position.

Preliminary Checks:

Transponder key is correct or not

Trouble Shooting:-

Step Checks

IF YES

IF NO

1.

Check the number of keys are learnt with immo =2

Go to next step

Learn the

transponder key

with immobilizer

2

Replace the key with new good one

Go to nest step

3.

Replace the immobilizer.

DTC’s confirmation:-

After rectification, ensure the following points by referring engine parameters using TML diagnostic tool before handing

over to customer.

Circuit Schematic Diagram:

Please refer the immobilizer circuit schematic

VICM

pin

no

Pin description

1

Vbatt (KL30)

2

GND

3

CAN_H(High-speed)

4

Ignition (KL15)

5

Status LED

6

Trasport Mode Fuse (10A)

7

Battery Supply (+Vbatt)
