Transponder & CAN based Immobilizer (Continental)
Part Replacement handling – Service Documentation
TITLE
: Immobilizer (Conti) Service Manual-Aria Eagle
xxxx
Date
: 28-08-2015
Version
: 0.1
Page
:
10 of 25
Prepared :
Amanulla Bugga
Approved: Dinesh G Dodmane
This specification is the exclusive property of Tata Motors Limited. Without their consent it may not be
reproduced or given to third parties
.
The above specifications are subject to change and therefore
suppliers are requested to refer the latest one.
CONTROLLED COPY FOR RESTRICTED CIRCULATION
42
15.
EMS and Immo handshake
failed
-
B1639-06 Blink ON
No
16.
No Signal from EMS after
Ignition ON
-
B1639-31 Blink ON
No
17.
Status lamp short to GND
or open circuit
-
B163A-14 OFF
OFF
yes
18.
Status Lamp short to Batt
-
B163A-12 ON
ON
yes
