Step Checks
IF YES
IF NO
1.
Remove TVA Actuator connector.
Go to Step 2.
-
2.
Identify the pin number 5 on the harness side connector.
Go to step 3.
-
3.
Check the continuity between pin 5 of the harness side
connector and battery positive.
There is a short
circuit in the harness
and perform repairs
accordingly.
Go to step 4.
4.
Check the continuity between pin 2 of the harness side
connector and battery positive.
There is a short
circuit in the harness
and perform repairs
accordingly.
Go to step 5.
5.
Are there any pins damaged at Sensor/EMS ECU
Connector.
Replace the
connector or wiring
Harness.
Go to step 6.
6.
Are there any pins backed out from the Sensor/EMS ECU
Connector.
Rectify/Replace
Connectors.
Go to Step 7.
7.
Is sensor physically Damaged?
Replace Sensor.
Go to Step 8.
8.
If fault still persists.
then replace sensor
and if fault still
persists then call
Hotline.
Follow the above
procedure again for
Reconfirmation.
DTC’s confirmation
(checks before handing over vehicle to customer)
:
1. Check the errors at Ignition ON, engine running @ Idle & Fly-up with different vehicle speeds also.
2. If error present, then rectify the errors.
3. Confirm that there is no error logged in EMS before handing over vehicle to customer.
