TURN ON IGNITION. CONNECT THE

DIAGNOSTIC TOOL AND CHECK FOR DTC’s

IS DTC

PRESENT?

CLEAR DTC. TURN OFF & ON IGNITION &

CHECK FOR DTC’s (at least 2 to 3 times)

IS DTC

STILL

PRESENT

TURN OFF IGNTION. AND REPLACE

DSP SENSOR

WITH A NEW ONE.

YES

TURN OFF &

ON IGNITION.

CLEAR DTC’s

& CHECK FOR

DTC’s

IS DTC

PRESENT?

TURN ON IGNITION.

CLEAR DTC’s & CHECK FOR DTC’s.

STOP

RE-CONNECT THE

AIRBAG ECU, W/H

& DSP

MODULE

VEHICLE

1.TURN OFF IGNITION.

2.REPLACE THE AIRBAG ECU WITHA NEW

ONE.

YES

IS DTC

STILL

PRESENT?

YES

START

B100C96::
