SRS / Airbag
ECU – DTC Troubleshooting Guide
Version: 14.0
Date: 14-February-2017
Prepared by:Airbag COC Review &
Approved by:Sanjeev VM
Page: 403 of 549
Connector View & Information:-
Fig364:- Driver side peripheral sensor connector view.
Fig365:- Airbag ECU connector interface.
Airbag ECU is fitted in the floor of central console in the car.
.
Fig:362 Airbag ECU location Fig:363 Airbag Wiring Harness connector
